    Rotary Face Mechanical Seal Carbon Ring M106k For Pump

    Ask Lasest Price
    Brand Name : JR
    Model Number : carbon
    Certification : iso9001
    Price : Negotiated
    Payment Terms : T/T, Western Union, L/C
    Supply Ability : 100000PC/Month
    Delivery Time : 20-30DAYS
    • Product Details
    • Company Profile

    Rotary Face Mechanical Seal Carbon Ring M106k For Pump

    Carbon Seal Rings Rotary Seal Face Mechanical Seals Carbon Sleeve M106k

    Description:


    slide bearing bush carbon graphite bearing ring

    Advantages of graphite bearing ring :
    1, high strength,high hardness
    2, good heat-resistance, low porosity
    3, anti-abrasion,anti-scour
    4, high purity graphite

    Application of graphite bearing ring :
    1, photovoltaic industry
    2, Precision casting industry ,coper continuous parts
    3, EDM graphite
    4, crucible for melting rare metals
    5, machine analysis container
    6, alloy industry, sintering molds


    Performance Capabilities



    Technical datas

    Unit

    M106K

    M158K

    M106D

    M106P

    Impregnated Materials

    Furan Resin

    Furan Resin

    Antimony Alloy

    Copper Alloy

    Shour hardness

    HS

    ≥90

    ≥85

    ≥85

    85

    porosity

    %

    1.5

    1.5

    2.5

    3

    Bulk density

    g/cm2

    ≥1.70

    ≥1.75

    ≥2.20

    ≥2.48

    Compressive strength

    MPa

    ≥240

    ≥200

    ≥190

    ≥240

    Bending strength

    MPa

    ≥65

    ≥60

    ≥65

    ≥70

    temperature limit

    200

    200

    400

    400

    Rotary Face Mechanical Seal Carbon Ring M106k For PumpRotary Face Mechanical Seal Carbon Ring M106k For PumpRotary Face Mechanical Seal Carbon Ring M106k For Pump

    We are engaged in manufacture and installation exporting and wholesaling quality range of Industrial Seal, Single Spring Seal, Balance and Unbalance Spring Seal, External Mounted Seal, PTFE Bellow External Mounted Seal, Catridge Balance Seal, Multiple Spring Balance Seal, Dry Running Reverse Balance Seal, Agitator Double Acting Unbalance Seal, Single Conical Helical Spring, Rubber Bellow Seal, Multi Spring Seal, Metal Bellow Seal, Elastomer Bellow Seal, Conical Spring Seal, Air Condition Compressor Seal, Auto Cooling Seal, Metallic Bellow Seal,

    All ranges of mechanical seals for Flygt Pumps, Grundfos Pumps, Pumps, APV Pumps, Grindes Pumps, Fristam, ABS, Alleeiler, EMU, GEA

    Tunchenhagen, Godwin, Hidrostal, Hilge, Johnson, Lowara, Waukesha, Vogelsang Pumps etc.


    At the meantime, we could manufacture seals according to your sample or drawing, and design as your request,Customization: Changes of materials for getting other operating parameters are possible. Contact us with your requirements.


    Question 1: Are you a factory or a trade company?
    Answer: We are a factory and have our top sales for the trade service.


    Question 2: Can I try to get a SAMPLE before the order?
    Answer: Sure. You can ask for the samples. Usually they're free.


    Question 3: Where is your factory located? How can I visit there?
    Answer: Our factory is located in Ningbo, China. You can fly to Ningbo or Shanghai airport directly. All our clients, from home or abroad, are warmly welcome to visit us!


    Question 4: How does your factory do regarding quality control?
    Answer: Quality is priority. We always attach great importance to quality controlling from the very beginning to the very end. Our factory has gained ISO9001 authentication.


    Question 5: How about the lead time?
    Answer: Within10-20 days after getting the prepayment.


    Question 6: How can we pay?
    Answer: For small sample shipping cost, you can pay either by paypal or by T/T. And by T/T at sight for large amount of the order.


    Question 7: If OEM available?
    Answer: Yes, we provide all of our products OEM /ODM service.


    Question 8: If I can buy pumps or pump parts from your company?
    Answer: Yes , we also provide pumps and pump parts, such as Lobe pumps, Compound & homogeneous pumps, Homogeneous & emulsification pumps and so on
