    Single Spring Mechanical Seal 166T For AESSEAL Replace FLOWSERVE 21

    Ask Lasest Price
    Brand Name : JR
    Model Number : Type 166T
    Certification : ISO9001
    Price : Negotiated
    Payment Terms : T/T, Western Union, L/C
    Supply Ability : 100000PC/Month
    Delivery Time : 20-30DAYS
    • Product Details
    • Company Profile

    Single Spring Mechanical Seal 166T For AESSEAL Replace FLOWSERVE 21

    Single-Spring Mechanical Seal 166T For AESSEAL (Replace FLOWSERVE 21)


    166T Single-Spring Mechanical Seal Replace AESSEAL (Replace FLOWSERVE 21)

    Operational Conditions:

    1. REPLACE FLOWSERVE TYPE 21
      Material:CE CA SIC TC V EPDM NBR 304 316

    2. Temperature: -20ºC to +120ºC
    3. Pressure: ≤1.4MPa
    4. Speed: ≤15m/s

    Materials:

    • ROTARY FACES: Carbon Graphite, Silicon Carbide, Tungsten Carbide
    • STATIONARY SEATS: Ceramic, Silicon Carbide, Tungsten Carbide, Stainless Steel
    • BELLOWS: Buna, FKM, EPDM, Aflas, Neoprene
    • METAL PARTS: 304 SS standard, 316 SS option available


    Performance Capabilities

    Temperature
    -30℃ to 200℃, dependent on the elastomer
    Pressure
    Up to 14 bar
    Speed
    Up to 13 m/s
    End play/axial float allowance
    ±0.1mm
    Size
    0.5" to 4"
    Brand
    JR
    Face
    Carbon, SiC, TC
    Seat
    Ceramic, SiC, TC
    Elastomer
    NBR, EPDM, FKM etc.
    Spring
    SS304, SS316
    Metal parts
    SS304, SS316
    Idividual Packing
    Using foam and plastic paper wrapped, then put one piece of seal in one box,finally put in standard export carton.

    Single Spring Mechanical Seal 166T For AESSEAL Replace FLOWSERVE 21Single Spring Mechanical Seal 166T For AESSEAL Replace FLOWSERVE 21Single Spring Mechanical Seal 166T For AESSEAL Replace FLOWSERVE 21

    We are engaged in manufacture and installation exporting and wholesaling quality range of Industrial Seal, Single Spring Seal, Balance and Unbalance Spring Seal, External Mounted Seal, PTFE Bellow External Mounted Seal, Catridge Balance Seal, Multiple Spring Balance Seal, Dry Running Reverse Balance Seal, Agitator Double Acting Unbalance Seal, Single Conical Helical Spring, Rubber Bellow Seal, Multi Spring Seal, Metal Bellow Seal, Elastomer Bellow Seal, Conical Spring Seal, Air Condition Compressor Seal, Auto Cooling Seal, Metallic Bellow Seal,

    All ranges of mechanical seals for Flygt Pumps, Grundfos Pumps, Pumps, APV Pumps, Grindes Pumps, Fristam, ABS, Alleeiler, EMU, GEA

    Tunchenhagen, Godwin, Hidrostal, Hilge, Johnson, Lowara, Waukesha, Vogelsang Pumps etc.


    At the meantime, we could manufacture seals according to your sample or drawing, and design as your request,Customization: Changes of materials for getting other operating parameters are possible. Contact us with your requirements.
