Single Spring Mechanical Seal 155 Burgmann BT-FN Replace AESSEAL T04 And Roten 3

Operational Conditions:

1. Shaft diameter (D1) : 10 ~ 60mm.
2. Temperature (t) : -30 ~ 100(200)℃.
3. Pressure (p1) : Up to 1.4MPa.
4. Speed (Vg) : 15 m/s (49 ft/s).

Materials:

• Seal face : Aluminium Oxide (05).
• Mating face : Carbon risin (06).
• Secondary seals : NBR(A), FKM(C).
• Combination : 0506A15.
