    Roten 2 Single Spring Mechanical Seal

    Ask Lasest Price
    Brand Name : JR
    Model Number : Roten 2
    Certification : ISO9001
    Price : Negotiated
    Payment Terms : T/T, Western Union, L/C
    Supply Ability : 100000PC/Month
    Delivery Time : 20-30DAYS
    • Product Details
    • Company Profile

    Roten 2 Single Spring Mechanical Seal

    Mechanical Seal Roten Seal Burgmann BT-RN NU Single Spring Roten Uniten 2 Seal


    Operational Conditions:

    1. Shaft diameter: d1 = 10 100 mm (0.39" ... 3.94")
    2. Pressure: Up to 10 bar (145 PSI),
    3. Temperature: t = -30 °C +200 °C (-22 °F +392 °F)
    4. Sliding velocity: vg = 10 m/s (2000 fpm)
    5. Admissible axial movement: ±2.0 mm

    Materials:

    • Stationary Ring: Ceramic, Silicon Carbide, TC
    • Rotary Ring: Carbon, Silicon Carbide
    • Secondary Seal: NBR, EPDM, FKM, PTFE
    • Spring and Metal Parts: Steel
    • 3. Seat Type:
    • 4. Applications: Clean water, sewage water, oil and other moderately corrosive fluids

    Performance Capabilities

    Roten 2 mechanical seal
    Operational Condtions
    Size
    Material
    Temperature:
    -30℃ to 200℃ dependent on the elastomer
    20mm to 100mm,
    Face: Carbon, SiC, TC
    Pressure:Up to 25 bar
    Seat: Ceramic, SiC, TC
    Speed:Up to 20 m/s
    Elastomer:NBR, EPDM, FKM
    End Play /axial float Allowance:±1.0mm
    Other Metal Part :SS304 SS316
    • 1. Features of structure:
    • Burgmann Bt-Rn Seals Roten 2 Seal Flowserve 42 Seal
    • 2.Our seals can replace the original seals.
    • 3.If it is not the one you need ,you can pass us your drawing ,material,shaft size for quotation.
    • 4.Customized products and OEM is welcomed
    • 5. 12 YEARS EXPERIENCE ,We provide Factory Price,High Quality ,Fast Delivery and Best Sevice.

    Roten 2 Single Spring Mechanical Seal

    We are engaged in manufacture and installation exporting and wholesaling quality range of Industrial Seal, Single Spring Seal, Balance and Unbalance Spring Seal, External Mounted Seal, PTFE Bellow External Mounted Seal, Catridge Balance Seal, Multiple Spring Balance Seal, Dry Running Reverse Balance Seal, Agitator Double Acting Unbalance Seal, Single Conical Helical Spring, Rubber Bellow Seal, Multi Spring Seal, Metal Bellow Seal, Elastomer Bellow Seal, Conical Spring Seal, Air Condition Compressor Seal, Auto Cooling Seal, Metallic Bellow Seal,


    All ranges of mechanical seals for Flygt Pumps, Grundfos Pumps, Pumps, APV Pumps, Grindes Pumps, Fristam, ABS, Alleeiler, EMU, GEA

    Tunchenhagen, Godwin, Hidrostal, Hilge, Johnson, Lowara, Waukesha, Vogelsang Pumps etc.


    At the meantime, we could manufacture seals according to your sample or drawing, and design as your request


    Question 1: Are you a factory or a trade company?
    Answer: We are a factory and have our top sales for the trade service.

    Question 2: Can I try to get a SAMPLE before the order?
    Answer: Sure. You can ask for the samples. Usually they're free.


    Question 3: Where is your factory located? How can I visit there?
    Answer: Our factory is located in Ningbo, China. You can fly to Ningbo or Shanghai airport directly. All our clients, from home or abroad, are warmly welcome to visit us!


    Question 4: How does your factory do regarding quality control?
    Answer: Quality is priority. We always attach great importance to quality controlling from the very beginning to the very end. Our factory has gained ISO9001 authentication.


    Question 5: How about the lead time?
    Answer: Within10-20 days after getting the prepayment.


    Question 6: How can we pay?
    Answer: For small sample shipping cost, you can pay either by paypal or by T/T. And by T/T at sight for large amount of the order.


    Question 7: If OEM available?
    Answer: Yes, we provide all of our products OEM /ODM service.


    Question 8: If I can buy pumps or pump parts from your company?
    Answer: Yes , we also provide pumps and pump parts, such as Lobe pumps, Compound & homogeneous pumps, Homogeneous & emulsification pumps and so on
